1 channel DIN rail relay switch with Wi-Fi, LAN and Bluetooth connection
Professional 1 channel relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms.
Shelly Pro 1
LAN, Wi-Fi, and Bluetooth connection
1 output, 16A
Dry contact
DIN rail mountable
POWER
Power supply AC
110-240V ±10%, 50/60Hz
Maximum load
16A
DC Output
0-30V; 12A
SPECIAL FUNCTIONS
Dry contacts
Yes
Roller shutter mode
No
Device temperature protection
Yes
Overload protection
Yes
Power measurement
No
FEATURES
HTTP/HTTPS webhooks
Yes
Custom scripts(mJs)
Yes
Channels
1 Channel
Operational temperature
0°C to + 40 °C
Device power consumption
< 4 W
Intelligent On/Off
Yes
Local and remote control
Yes
Sunrise/Sunset
Yes
Weekly Schedule
Yes
UL Listed option
No
CONNECTIVITY
Wireless
Yes
Wi-Fi Protocol
802.11 b/g/n
Wi-Fi Radio frequency
2412 - 2484 MHz
Wi-Fi Radio signal power
1mW
Wi-Fi Range
up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
Bluetooth
Yes
Ethernet
Yes
DIMENSIONS
Size
18,5mm x 89,5mm x 68,5mm
1 channel DIN rail relay switch with power metering and Wi-Fi, LAN and Bluetooth connection
Professional 1 channel relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control and precise power management. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms.
Shelly Pro 1PM
LAN, Wi-Fi, and Bluetooth connection
1 output, 16A
Power metering
DIN rail mountable
POWER
Power supply AC
110-240V ±10%, 50/60Hz
Maximum load
16A
Device temperature protection
Yes
Overload protection
Yes
Power measurement
Yes
FEATURES
HTTP/HTTPS webhooks
Yes
Custom scripts(mJs)
Yes
Channels
1 Channel
Operational temperature
0°C to + 40 °C
Device power consumption
< 4 W
Intelligent On/Off
Yes
Local and remote control
Yes
Sunrise/Sunset
Yes
Weekly Schedule
Yes
UL Listed option
No
CONNECTIVITY
Wireless
Yes
Wi-Fi Protocol
802.11 b/g/n
Wi-Fi Radio frequency
2412 - 2484 MHz
Wi-Fi Radio signal power
1mW
Wi-Fi Range
up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
Bluetooth
Yes
Ethernet
Yes
DIMENSIONS
Size
18,5mm x 89,5mm x 68,5mm
2 channels DIN rail relay switch with Wi-Fi, LAN and Bluetooth connection
Professional 2 channels relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms.
Shelly Pro 2
LAN, Wi-Fi, and Bluetooth connection
2 output, 16A each. Total device maximum of 25A
Dry contact
DIN rail mountable
2 phases control
POWER
Power supply AC
110-240V ±10%, 50/60Hz
Maximum load
up to 16A per channel with up to 25A for the whole device
Power supply DC
no support
SPECIAL FUNCTIONS
Roller shutter mode
No
Device temperature protection
Yes
Overload protection
Yes
Power measurement
No
FEATURES
HTTP/HTTPS webhooks
Yes
Custom scripts(mJs)
Yes
Channels
2 Channel
Operational temperature
0°C to + 40 °C
Device power consumption
< 4 W
Intelligent On/Off
Yes
Local and remote control
Yes
Sunrise/Sunset
Yes
Weekly Schedule
Yes
UL Listed option
No
CONNECTIVITY
Wireless
Yes
Wi-Fi Protocol
802.11 b/g/n
Wi-Fi Radio frequency
2412 - 2484 MHz
Wi-Fi Radio signal power
1mW
Wi-Fi Range
up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
Bluetooth
Yes
Ethernet
Yes
DIMENSIONS
Size
18,5mm x89,5mm x 68,5mm
2 channel DIN rail relay switch with power metering and Wi-Fi, LAN and Bluetooth connection
Professional 2 channel relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control and precise power management. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms.
Shelly Pro 2PM
LAN, Wi-Fi, and Bluetooth connection
2 output, 16A each. Total device maximum of 25A
Power metering
DIN rail mountable
Roller Shutter - Requires upcoming firmware update of the device.
POWER
Power supply AC
110-230V ±10%, 50/60Hz
Maximum load
2 outputs, 16A each. Total device maximum of 25A
Power supply DC
12V DC ±10%
SPECIAL FUNCTIONS
Roller shutter mode
Requires upcoming firmware update of the device.
Device temperature protection
Yes
Overload protection
Yes
Power measurement
Yes
FEATURES
HTTP/HTTPS webhooks
Yes
Custom scripts(mJs)
Yes
Channels
2 Channel
Operational temperature
0°C to + 40 °C
Device power consumption
< 4 W
Intelligent On/Off
Yes
Local and remote control
Yes
Sunrise/Sunset
Yes
Weekly Schedule
Yes
UL Listed option
No
CONNECTIVITY
Wireless
Yes
Wi-Fi Protocol
802.11 b/g/n
Wi-Fi Radio frequency
2412 - 2484 MHz
Wi-Fi Radio signal power
1mW
Wi-Fi Range
up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
Bluetooth
Yes
Ethernet
Yes
DIMENSIONS
Size
18,5mm x 89,5mm x 68,5mm
Shelly Pro 4PM
4 channels DIN rail relay switch with Wi-Fi, LAN and Bluetooth connection
Professional 4 channels relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control and precise power management. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms.
Shelly Pro 4PM
LAN, Wi-Fi, and Bluetooth connection
4 outputs, 16A each. Total device maximum of 40A
Precise power metering
Overpower and overvoltage protection of the load.
DIN rail mountable
1.8-inch color screen with navigation keys
POWER
Power supply AC
110-230V ±10%, 50/60Hz
Power supply DC
No
SPECIAL FUNCTIONS
Roller shutter mode
No
Device temperature protection
Yes
Overload protection
Yes
Power measurement
Yes
FEATURES
HTTP/HTTPS webhooks
Yes
Custom scripts(mJs)
Yes
Channels
4 Channel
Maximum load
up to 16A per channel with up to 40A for the whole device
Operational temperature
0°C to + 40 °C
Device power consumption
< 4 W
Intelligent On/Off
Yes
Local and remote control
Yes
Sunrise/Sunset
Yes
Weekly Schedule
Yes
UL Listed option
No
CONNECTIVITY
Wireless
Yes
Wi-Fi Protocol
802.11 b/g/n
Wi-Fi Radio frequency
2412 - 2484 MHz
Wi-Fi Radio signal power
1mW
Wi-Fi Range
up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
Bluetooth
Yes
Ethernet
Yes
DIMENSIONS
Size
90mm x 52mm x 57mm
