Pro Line

1 channel DIN rail relay switch with Wi-Fi, LAN and Bluetooth connection Professional 1 channel relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms. Shelly Pro 1 LAN, Wi-Fi, and Bluetooth connection 1 output, 16A  Dry contact DIN rail mountable POWER Power supply AC 110-240V ±10%, 50/60Hz Maximum load 16A DC Output 0-30V; 12A SPECIAL FUNCTIONS Dry contacts Yes Roller shutter mode No Device temperature protection Yes Overload protection Yes Power measurement No FEATURES HTTP/HTTPS webhooks Yes Custom scripts(mJs) Yes Channels 1 Channel Operational temperature 0°C to + 40 °C Device power consumption < 4 W Intelligent On/Off Yes Local and remote control Yes Sunrise/Sunset Yes Weekly Schedule Yes UL Listed option No CONNECTIVITY Wireless Yes Wi-Fi Protocol 802.11 b/g/n Wi-Fi Radio frequency 2412 - 2484 MHz Wi-Fi Radio signal power 1mW Wi-Fi Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials) Bluetooth Yes Ethernet Yes DIMENSIONS Size 18,5mm x 89,5mm x 68,5mm

1 channel DIN rail relay switch with power metering and Wi-Fi, LAN and Bluetooth connection Professional 1 channel relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control and precise power management. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms. Shelly Pro 1PM LAN, Wi-Fi, and Bluetooth connection 1 output, 16A  Power metering DIN rail mountable POWER Power supply AC 110-240V ±10%, 50/60Hz Maximum load 16A Device temperature protection Yes Overload protection Yes Power measurement Yes FEATURES HTTP/HTTPS webhooks Yes Custom scripts(mJs) Yes Channels 1 Channel Operational temperature 0°C to + 40 °C Device power consumption < 4 W Intelligent On/Off Yes Local and remote control Yes Sunrise/Sunset Yes Weekly Schedule Yes UL Listed option No CONNECTIVITY Wireless Yes Wi-Fi Protocol 802.11 b/g/n Wi-Fi Radio frequency 2412 - 2484 MHz Wi-Fi Radio signal power 1mW Wi-Fi Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials) Bluetooth Yes Ethernet Yes DIMENSIONS Size 18,5mm x 89,5mm x 68,5mm

2 channels DIN rail relay switch with Wi-Fi, LAN and Bluetooth connection Professional 2 channels relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms. Shelly Pro 2 LAN, Wi-Fi, and Bluetooth connection 2 output, 16A each. Total device maximum of 25A Dry contact DIN rail mountable 2 phases control POWER Power supply AC 110-240V ±10%, 50/60Hz Maximum load up to 16A per channel with up to 25A for the whole device Power supply DC no support SPECIAL FUNCTIONS Roller shutter mode No Device temperature protection Yes Overload protection Yes Power measurement No FEATURES HTTP/HTTPS webhooks Yes Custom scripts(mJs) Yes Channels 2 Channel Operational temperature 0°C to + 40 °C Device power consumption < 4 W Intelligent On/Off Yes Local and remote control Yes Sunrise/Sunset Yes Weekly Schedule Yes UL Listed option No CONNECTIVITY Wireless Yes Wi-Fi Protocol 802.11 b/g/n Wi-Fi Radio frequency 2412 - 2484 MHz Wi-Fi Radio signal power 1mW Wi-Fi Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials) Bluetooth Yes Ethernet Yes DIMENSIONS Size 18,5mm x89,5mm x 68,5mm

2 channel DIN rail relay switch with power metering and Wi-Fi, LAN and Bluetooth connection Professional 2 channel relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control and precise power management. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms. Shelly Pro 2PM LAN, Wi-Fi, and Bluetooth connection 2 output, 16A each. Total device maximum of 25A Power metering DIN rail mountable Roller Shutter - Requires upcoming firmware update of the device. POWER Power supply AC 110-230V ±10%, 50/60Hz Maximum load 2 outputs, 16A each. Total device maximum of 25A Power supply DC 12V DC ±10% SPECIAL FUNCTIONS Roller shutter mode Requires upcoming firmware update of the device. Device temperature protection Yes Overload protection Yes Power measurement Yes FEATURES HTTP/HTTPS webhooks Yes Custom scripts(mJs) Yes Channels 2 Channel Operational temperature 0°C to + 40 °C Device power consumption < 4 W Intelligent On/Off Yes Local and remote control Yes Sunrise/Sunset Yes Weekly Schedule Yes UL Listed option No CONNECTIVITY Wireless Yes Wi-Fi Protocol 802.11 b/g/n Wi-Fi Radio frequency 2412 - 2484 MHz Wi-Fi Radio signal power 1mW Wi-Fi Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials) Bluetooth Yes Ethernet Yes DIMENSIONS Size 18,5mm x 89,5mm x 68,5mm

Shelly Pro 4PM 4 channels DIN rail relay switch with Wi-Fi, LAN and Bluetooth connection Professional 4 channels relay with Wi-Fi, LAN, and Bluetooth connection, suitable for home and facility automation with remote control and precise power management. DIN rail mountable insde a breaker box. Enhanced safety features and compatible with most used home automation platforms. Shelly Pro 4PM LAN, Wi-Fi, and Bluetooth connection 4 outputs, 16A each. Total device maximum of 40A Precise power metering Overpower and overvoltage protection of the load. DIN rail mountable 1.8-inch color screen with navigation keys POWER Power supply AC 110-230V ±10%, 50/60Hz Power supply DC No SPECIAL FUNCTIONS Roller shutter mode No Device temperature protection Yes Overload protection Yes Power measurement Yes FEATURES HTTP/HTTPS webhooks Yes Custom scripts(mJs) Yes Channels 4 Channel Maximum load up to 16A per channel with up to 40A for the whole device Operational temperature 0°C to + 40 °C Device power consumption < 4 W Intelligent On/Off Yes Local and remote control Yes Sunrise/Sunset Yes Weekly Schedule Yes UL Listed option No CONNECTIVITY Wireless Yes Wi-Fi Protocol 802.11 b/g/n Wi-Fi Radio frequency 2412 - 2484 MHz Wi-Fi Radio signal power 1mW Wi-Fi Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials) Bluetooth Yes Ethernet Yes DIMENSIONS Size 90mm x 52mm x 57mm
